Flocculant / Anionic flocculant of AN 934 VHM AN 923 SH AN 923 VHM can be replaced by Chinafloc
Anionic flocculant of AN 934 VHM AN 923 SH AN 923 VHM can be replaced by Chinafloc
.jpg)
An934 VHM is a kind of anionic flocculant with 30% charge and ultra high molecular weight.
An923SH is a kind of Anionic flocculant with 20% chagre and very very high molecular weight
An923 VHM is a kind of anionic flocculant with 20% charge and ultra high molecular weight
mainly used for mineral processing and oil drilling .Chinafloc A3020 and Chinafloc A2015 and Chinafloc A2520 can replace of them with good performance.
1. Product characteristics
Anionic flocculant(APAM)series products are water-soluable linear polymers synthesized under high degree polymerization,easily soluble in water,almost insoluble in benzene,ether,aliphatics,acetone and other common organic solvents .at the meantime,APAM series products also have valuable properties like flocculation,thickening,shear property,drag-reduction and dispersibility.thus widely used in oil recovery,
mineral processing,coal washing,metallurgy,chemicals,paper,textile,suger,medicine,environmental protection,building materials,agriculture and other industtries.
2. Quality index
|
Product Name |
Model |
Solid Content(%) |
Molecular Weight (Million) |
Hydrolysis degree(%) |
Application |
|
ChinaflocA2718 ChinaflocA3018 ChinaflocA2720 |
≥89% |
High High High |
Medium High Memium |
Oil drilling mud additive |
|
|
ChinaflocA2320 ChinaflocA3020 ChinaflocA2523 |
≥89% |
Very high Very high Very high |
Medium High Medium |
EOR (Enhanced Oil Recovery)
|
|
|
ChinaflocA2015 ChinaflocA2520 Chinfloc A3016 |
≥89% |
Medium High Medium |
Medium Medium Medium |
Mineral processing |
|
|
ChinaflocA2718 ChinaflocA3018 ChinaflocA2818 ChinaflocA2518 |
≥89% |
High High High High |
Medium Medium Medium Medium |
Industrial Wastewater treatment |
3. Application
(1)Drilling mud material.
Used as drilling mud additives in oilfield exploration and development and geology,water conservancy and coal exploration.i can prolong the bit’s life,raise the drilling rate and drilling footage,reduce the time of exchange drills.it has obvious effect in avoiding well collapse.it can also be used as oilfield fracturing fluid and profiling water blocking agent.
(2)Displacement agent for tertiary recovery of oilfield.
It can adjust the rheology of water injection,increase the viscosity of Displacing liquid,improve the spreading efficiency of liquid displacement ,bring down the water permeability in strata and keep water and oil to flow at a constant speed.it is mainly used in tertiary recovery of oilfields.injection of each ton of PAM products can help to gather 100-150 tons extra crude oil.
(3) Industrial wastewater treatment.
Especially for the treatment of wastewater containing suspendent particles which is coarse,high concentration and with positive charges and water’s PH value is neutral or alkaline.most effective for wastewater treatment of iron and steel plant,electroplate factory,metallurgy and coal washing.
(4)Drinking water treatment.
Many water plants in China come from river water,which contains large sum of sediment and mineral,very turbid.after precipitation and filtration,it still can not meet the requirements.flocculant is needed.water plants used to use inorganic flocculants.but large additive amount is required which caused the increase of sludge volume,not effective.use anionic PAM flocculants,with 1/50 additive amount that of inorganic flocculants,several times and even dozens of times effectiveness obtained than that of inorganic flocculants.for those organic polluted river water,better effectiveness can be achieved while mixed used together with cationic PAM.
(5)Papermaking additives.
Can be used for caustic soda’s clarification.used as retention aid,filter aid,reinforcing agent for wet and dry paper.
(6)Clarifying agent in sugar refining industry.
(7)Additives and adhesives in aquatic product feedstuff.
（8）used for construction bored pile
4. Instruction for use
(1)It's very important to make the efficient dispersion during using, otherwise will cause agglomerate and "fish eyes", dissolving time will be longer.
(2)Low-hardness water for use; avoid adopting such tank or pool, which will influence on water quality.
(3)Improve the water temperature to accelerate the dissolving velocity, but not exceed 50.
(4)Stirring will accelerate dissolving, but tough stirring will make the dispersant chain broken and degradation. Shipshape agitator with 200 - 500 rpm is the best choice.
(5)Commonly mix the product into 0.05%--0.5%(w/w)solution as reserve.
(6)Adjust the optimum dosage of product according to application condition.
5. Product package
25 Kg PE bags or kraft bags with plastic inner
6. Attention
The product is moisture absorbent, thus to protect from damp and moist for conservation. It should be stored in a dry and ventilate storehouse, and not be exposed to air and sunshine.
tag:anionic flocculant,AN 934 VHM,AN 923 SH,AN 923 VHM
