PHPA Polymer(anionic polyacrylamide) used for oil displacement(EOR)

1. Product characteristics

This product is a trpe of ultra-high molecular polyacrylamide specifically produced for oilfield polymer flooding process(EOR)by adopting a new technology.highest molecular weight goes uo tp 25million,moderate hydrolysis,high viscosity and fine solubility.

2.specifications

Specification

SH-EOR-1

SH-EOR-2

SH-EOR-3

SH-EOR-4

Solid content(%)

≥89

Molecular weight(million)

10-13

14-17

18-20

21-25

Hydrolysis degree(%)

≤24

Dissolution  time(h)

≤2

Viscossity(mpa.s)

Concentration(1000mg/l)

Mineralization(5727mg/l)

Test temperature(70℃)

≥8.5

≥10.5

≥11.5

≥12.5

Viscossity(mpa.s)

Concentration(1000mg/l)

Mineralization(1000mg/l)

Test temperature(45℃)

≥30

≥40

≥50

≥60

3. Application

Oilfield displacement agent.when the oilfield cones into tertiary recovery period,single waterflodding oil displacement method,since its flow rate is higher than that of the underground crude oil it drives,will greatly reduce its spreading efficiency and increase water consumption,and greatly increase the water content of the crude oil collected.in addition,nonuniformity of oil pool’s geology will also reduce the spreading efficiency.for special oil layer of positive rhythm deposition.upper thick and lower thin,lower part permeability higher than the upper part.when displacing oil by single waterflooding,it usually spreads along the bottom,while leaving large amount of crude oil in the upper part the oil layer undisplaced,using polyacrylamide which can increase the viscosity of water in stead of single waterflooding will help to improve the spreading efficiency and reduce water content of crude oil,increase oil production.our company’s partial hydrolysis polyacrylamide fully meets up with requirements of oilfield’s tertiary recovery(EOR)users can select to use according to different characters of different oilfield such as formation temperature,mineralization,viscosity of polymer solution injected and etc.

4. Product package

25 Kg paper plastic three-in-one compound woven bags, or according to users’ requirement; Its shelf life is 2 years.

5. Attention

The product is moisture absorbent, thus to protect from damp and moist for conservation. It should be stored in a dry and ventilate storehouse, and not be exposed to air and sunshine.
